- E-bike
-
- UI/Remote
- All New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized app
-
- Motor
- All New Specialized 3.1 Motor, 101Nm torque, 666W power
-
- Charger
- Specialized 4amp charger
-
- Battery
- 840Wh battery
- Frameset
-
- Seat Binder
- Alloy, 38.6mm
-
- Frame
- All new Levo 4 frame, FACT 11m carbon chassis and rear-end, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, w/ SWAT storage, 150mm of travel, side entry battery, fork travel up to 180mm
- Suspension
-
- Fork
- FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm axle, 44mm offset, 160mm of travel
-
- Rear Shock
- FOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment
- Brakes
-
- Front Brake
- SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm Rotor
-
- Rear Brake
- SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm Rotor
- Drivetrain
-
- Cassette
- SRAM 1270 Transmission Cassette, 12 Spd,10-52t
-
- Chainrings
- SRAM T-type ring, 34T, 104 BCD, steel
-
- Shift Levers
- SRAM AXS POD Controller
-
- Chain
- SRAM GX Eagle Transmission Flattop Chain
-
- Rear Derailleur
- SRAM S1000 Eagle Transmission, Wired SRAM AXS battery (powers AXS rear derailleur with integrated hot shoe directly off the Levo 4 main battery).
-
- Crankset
- SRAM S1000 Crankset, ISIS interface, Integrated Guard, 55mm Chainline, 155mm
- Wheels & tires
-
- Front Hub
- Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
-
- Rear Tire
- Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"
-
- Front Tire
- Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
-
- Spokes
- DT Swiss Industry
-
- Rear Hub
- Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
-
- Rims
- Specialized 29, hookless alloy, 30mm inner width, tubeless ready
-
- Inner Tubes
- Standard, Presta valve
- Cockpit
-
- Stem
- Alloy Trail Stem, 35mm bar bore
-
- Handlebars
- Alloy handlebars, 35mm diameter, 8 degree back sweep, 6 degree up sweep, S1/S2: 780mm/30mm rise, S3-S6: 800mm/50mm rise
-
- Saddle
- Bridge Comp, Hollow Cr-mo rails
-
- Grips
- Specialized Trail Grips
-
- SeatPost
- Xfusion Manic, infinite adjustable, two bolt head, Remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 190mm
- Accessories
-
- SWAT
- SWAT internal downtube storage
- Product details
-
- Product ID
- 218709
-
- Compliance Certification
- As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS. <br>For information on lithium-ion battery standards and regulations in New York City, visit: [www.nyc.gov/fdny/batteries](https://www.nyc.gov/fdny/batteries)
- Weight
-
- Weight
- 24.41 kg (53 lb, 13.0 oz)
-
- Weight Size
- S4
