- E-bike
-
- UI/Remote
- All New MasterMind T3 Display System, 2.2" high resolution color screen, fully customizeable with Specialized App
-
- Motor
- All New Specialized 3.1 Motor, 101Nm torque, 666W power
-
- Charger
- Specialized 4amp charger
-
- Battery
- 840Wh battery
- Frameset
-
- Seat Binder
- Alloy, 38.6mm
-
- Frame
- All new Levo 4 M5 Alloy frame, 150mm travel,, adjustable chainstay, adjustable head tube angle, adjustable bottom bracket, internal SWAT storage 148mm spacing, 29" front wheel/27.5" rear wheel, fork travel up to 180mm
- Suspension
-
- Rear Shock
- *Marzocchi Bomber Inline, EVOL LV air sleeve, rebound adjust, 210x55mm
-
- Fork
- Marzocchi Bomber Z1, 29", S2-S6: 160mm, S1: 150mm, sweep adjust compression
- Brakes
-
- Front Brake
- SRAM DB8 Stealth, 4-piston caliper, hydraulic disc, 220mm Centerline rotor
-
- Rear Brake
- SRAM DB8 Stealth, 4-piston caliper, hydraulic disc, 200mm Centerline rotor
- Drivetrain
-
- Cassette
- XS-1270, 12-speed, 10-52t
-
- Chainrings
- SRAM 34t T-Type chainring, 104 BCD, steel
-
- Chain
- SRAM Eagle 70 T-Type Flattop Chain
-
- Rear Derailleur
- SRAM Eagle 70 T-Type
-
- Shift Levers
- SRAM 70 trigger, 12-speed, single click
-
- Crankset
- SRAM S1000 Crankset, ISIS Interface, Integrated Guard, 55mm Chainline, 155mm
- Wheels & tires
-
- Rear Tire
- Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, TLR, 27.5x2.4"
-
- Front Tire
- Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, TLR, 29x2.4"
-
- Spokes
- DT Swiss Elemental
-
- Front Hub
- Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
-
- Rear Hub
- Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
-
- Rims
- Specialized, hookless alloy, 30mm inner width, tubeless ready
-
- Inner Tubes
- Standard, Presta Valve
- Cockpit
-
- Stem
- Alloy Trail Stem, 35mm bar bore
-
- Handlebars
- Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, S1-S2: 780mm width, S3-S6 800mm width
-
- Saddle
- Body Geometry Bridge Saddle, steel rails
-
- Grips
- Specialized Trail Grips
-
- SeatPost
- TranzX dropper, 34.9mm, S1: 100mm, S2: 125mm, S3: 150mm. S4-S5: 170mm, S6: 200mm
- Accessories
-
- SWAT
- SWAT Internal downtube storage
- Product details
-
- Product ID
- 221348
-
- Compliance Certification
- As applicable, certified to UL 2849 (e-system) and/or UL 2271 (battery) by UL Solutions and/or SGS.
For information on lithium-ion battery standards and regulations in New York City, visit: [www.nyc.gov/fdny/batteries](https://www.nyc.gov/fdny/batteries)
- Weight
-
- Weight
- 26.08 kg (57 lb, 7.8 oz)
-
- Weight Size
- S4
